15
MECHANICAL ROOM ADJUSTMENT
Vertical & Horizontal Room Adjustment
NOTE: All slideout room adjustments must be performed by certified
service technicians. Adjustments made by non-certified
persons may void any and all warranty claims.
Horizontal adjustment - See pg. 17, Fig. 8
1. Loosen 2 carriage bolts “A” on each bracket located at the end
of each guide tube.
2. Room is ready to be positioned horizontally by pushing on the
outside, sidewall or by using a prying devise inserted into the
opening between the room and coach.
Note: Use caution when using prying devise so seals do not become
damaged.
Vertical adjustment - See pg. 17, Fig. 9
1. Loosen 2 carriage bolts “A” on each bracket located at the end of
each guide tube
2. Loosen jam nut
3. For vertical adjustment turn vertical adjustment bolt “B” up or
down to locate room height.
Once room is located, tighten “A” and Jam Nut bolts.
