PARTS LIST, GPS-1 & VARIANTS:
WHEN ORDERING PARTS, GIVE SIZE, CLASS, PART NAME, AND PART REFERENCE NUMBER FROM TABLE
BELOW. USE PART NUMBER ONLY TO LOCATE PART ON DRAWING.
PART
PART NAME
MATERIAL
MATERIAL SPECIFICATION
QTY.
NO.
A) COMMON PARTS:
1
ADAPTER
BRASS
ASTM-B16
1
3
BOLT
STEEL
COMMERCIAL
(NOTE 1)
4
NUT
STEEL
COMMERCIAL
(NOTE 17)
6
DIAPHRAGM DISC
(NOTE 9)
COMMERCIAL
1
7 *
MAIN VALVE GUIDE
BRONZE
ASTM-B21, ALLOY C46400
1
8
BODY THREADED
CAST STEEL
ASTM-A216, GR, WCB
1
8
BODY S.O. FLG
CAST STEEL
ASTM-A216, GR, WCB
1
8
BODY 150# FLG
CAST STEEL
ASTM-A216, GR. WCB
1
8
BODY 300# FLG
CAST STEEL
ASTM-A216, GR. WCB
1
8
BODY S.W.E.
CAST STEEL
ASTM-A216, GR. WCB
1
9
MAIN VALVE COMPLETE
STAINLESS STEEL
AISI 17-4 PH
1
11
MAIN VALVE SPRING
STAINLESS STEEL
AISI TYPE 300
1
12+
BOTTOM CAP GASKET
COPPER
ASTM-B152
1
12+
BOTTOM CAP GASKET
NON-ASBESTOS
COMMERCIAL
1
13
BOTTOM CAP (NOTE 2)
CAST STEEL
ASTM-A216, GR. WCB
1
14
BOTTOM CAP BUSHING
BRONZE
ASTM-B21, ALLOY C46400
1
15
BOLT
STEEL
COMMERCIAL
8
16+
BOLT`
STEEL
COMMERCIAL
(NOTE 5)
17
DIAPHRAGM BASE
CAST STEEL
ASTM-A216, GR. WCB
1
19
DIAPHRAGM BASE GASKET
SHEET PACKING
COMMERCIAL
1
20
LOCK WASHER
STEEL
COMMERCIAL
(NOTE 5)
21
RETAINING RING
STEEL
AISI 1018
2
22
SLIP-ON FLANGE, 150#
STEEL
COMMERCIAL
2
23
SLIP-ON FLANGE, 300#
STEEL
COMMERCIAL
2
SEAT RING WRENCH
STEEL
ASTM-A519, GR. 1015
1
B)
1/2" - 4" GPS-1 & 1/2" - 4" GPS-1S
2+
DIAPHRAGM
STAINLESS STEEL
AISI TYPE 316
2
5
DIAPHRAGM
CARBON STEEL
ASTM A-285, GR. C
1
10 *
SEAT RING, -1
(NOTE 6)
(NOTE 6)
1
10 *
SEAT RING, -IS
STELLITED SST
(NOTE 8)
1
+ RECOMMENDED SPARE PARTS.
* THESE PARTS, PLUS RECOMMENDED SPARE PARTS, SHOULD BE ON HAND WHEN OVERHAULING THIS
EQUIPMENT.
