Leslie Controls GP Pressure reducing valve User Manual
Page 23
Page 23
NOM.
NET
PIPE
A
B
C
C-D
J
K
L
M
N
WT.*
SIZE
1/2"
8-1/2
5-1/2
3-3/8
6-3/8
8-5/8
3-5/8
3/8
35/64
.855
39 lb
15MM
215.9
139.7
85.7
161.9
219.1
92.1
9.5
13.9
21.7
17.7 kg
3/4"
8-1/2
5-1/2
3-3/8
6-3/8
8-5/8
3-5/8
1/2
3/4
1.065
41.8 lb
20MM
215.9
139.7
85.7
161.9
219.1
92.1
12.7
19.1
27.1
19.0 kg
1"
8-1/2
5-1/2
3-3/8
6-3/8
8-5/8
3-29/32
1/2
61/64
1.330
48.7 lb
25MM
215.9
139.7
85.7
161.9
219.1
99.2
12.7
24.2
33.8
22.2 kg
1-1/2"
9-1/2
6-1/16
4+1/2
7-1/2
10-1/4
4-5/16
1/2
1-1/2
1.915
65 lb
40MM
241.3
154.0
114.3
190.5
260.4
109.5
12.7
38.1
48.6
29.5 kg
2"
11-1/2
6-1/16
4-1/2
7-1/2
10-1/4
4-5/16
5/8
1-15/16
2.406
70 lb
50MM
292.1
154.0
114.3
190.5
260.4
109.5
15.9
49.2
61.1
31.8 kg
