1-1
1124 100Base-TX Repeater User Guide
Writer: Chris Seiter Project: Introduction Comments: 185810-110/707119-001
File Name:10024_1.DOC Last Saved On:3/13/96 5:15 PM
Chapter 1
Introduction
Compaq’s Netelligent 1124 100Base-TX Repeater provides functionality for
24 RJ-45 ports. The repeater's uplink capability lets you connect the repeater
to another repeater or other 100Base-TX repeater. For backup power, you can
install an optional redundant power supply. The repeater's front panel makes it
easy to view the current operating status.
Features
The repeater includes these features:
■ Twenty-four shielded RJ-45 ports that support 100Base-TX
connections
■ Uplink port that enables bridging to 100Base-TX topologies
■ LEDs that indicate power supply status (A and B), collisions, and port
link/activity/partition status
■ Modular power supply design for easy removal and replacement
■ Auto-sensing power supply operates within the range of a 100 to 240
VAC, 50 to 60 Hz power source
■ Optional dual-redundant power supply
■ Class II support for 100Base-TX
■ Compatibility with the IEEE 802.3u 100Base-TX repeater specification
■ Chassis that can stand alone or be mounted in a standard, EIA 19-inch
rack
■ Surface-mount technology
