2-1
1124 100Base-TX Repeater User Guide
Writer: Chris Seiter Project: Planning Repeater Installation Comments: 185810-001/707119-001
File Name:10024_2.DOC Last Saved On:3/13/96 6:03 PM
Chapter 2
Planning Repeater Installation
This chapter contains installation requirements and system planning charts
that will help you prepare for installing the repeater.
Installation Requirements
To help ensure a correct installation, read this section to determine the
environmental, electrical, spatial, and cable requirements.
Environmental Requirements
Be sure the operating environment for the repeater is within the following
ranges:
■ Temperature: 32
°
to 122
°
F (0
°
to 50
°
C)
■ Humidity: 5% to 95% (non-condensing)
■ Altitude: 0 to 10,000 feet (0 to 3 km)
■ Clearance: minimum of 2 inches (5.1 centimeters) on each side of the
repeater for proper ventilation
Electrical Requirements
The electrical requirements for a repeater are as follows:
■ 100 to 240 VAC
■ 1.5 to 0.75 Amps (1.5 Amps @ 100 VAC to 0.75 A @ 240 VAC)
■ 50 to 60 Hz
