3-1
1124 100Base-TX Repeater User Guide
Writer: Chris Seiter Project: Installing the Repeater Comments: 185810-001/707119-001
File Name:10024_3.DOC Last Saved On:3/14/96 11:56 AM
Chapter 3
Installing the Repeater
This chapter explains how to mount the repeater, attach cables, and
interconnect the repeater to a second repeater.
Mounting the Repeater
You can place the repeater on a level surface (table top or shelf, for example)
or mount it in a standard EIA 19-inch rack.
Attaching the Rubber Feet
If you will place the repeater on a table top or shelf, attach the supplied
adhesive-backed rubber feet as described in the following steps.
1. Turn the repeater over so that its bottom side faces up.
2. Remove the four rubber feet from their packaging.
3. Peel the protective paper backing off the rubber feet. Then position the
feet in the recessed areas near the corners of the repeater and press the
feet into place.
4. Turn the repeater to its upright position and place it on the mounting
surface.
NOTE: Be sure you allow at least 2 inches (5 cm) on each side of the repeater for
proper air flow.
Rack-Mounting the Repeater
The repeater occupies two slots in a standard, 19-inch rack. To mount the
repeater in a rack, use the two side mounting brackets, eight smaller bracket
screws, and four larger rack-mount screws.
To attach the brackets, follow these steps:
