TA - U0 - EF
Litho in U.S.A.
2150 N. RULON WHITE BLVD., OGDEN, UT 84404
Phone: 1-800-368-2493 www.chromalox.com
OPERATION
MAINTENANCE
RENEWAL PARTS IDENTIFICATION
WARNING: Type CVCHS Circulation Heaters are
equipped with INCOLOY
® heating elements and cen-
tered in a CVPVC pipe body. It is the responsibility of
the user to know the chemical composition of the
corrosive solution and the character of the materials
entering the solution as well as the corrosive effect
of the solution upon the heating elements and cham-
ber. Chromalox cannot warrant any electric circula-
tion heater against failure by sheath corrosion if
such failure is the result of operating conditions
beyond our control.
WARNING:
1. Do not permit heater to operate when liquid has been drained
from chamber. Dry operation of the heater will cause failure and
possible fire hazard.
2. Terminal ends of heater must be protected from drippings, con-
densation, spray or direct spill-over of material. Their presence
at the terminals may damage heater electrical insulation. Liquid-
tight terminal enclosures are available to protect heater. Check
Factory.
1. WARNING: Hazard of Shock. Disconnect all power
before servicing heater.
2. If automatic reset cutout fails or will not reset, do not bypass.
3. Remove heating element assembly periodically to check heater
sheath for scaling, corrosion or excessive oxidation. Correct
operating conditions to minimize sheath deterioration.
4. Periodically check temperature control operation to insure accu-
rate and safe process operation.
5. Check all electrical connections periodically and retighten con-
nections which may have loosened in service. Replace wire and
wire terminals which shows signs of oxidation which would inter-
fere with establishment of reliable electrical connections.
Note: When ordering parts for Model Numbers suffixed by “XX” or any other letter or letters not specifically identified on this instruction sheet, order Renewal Parts
on special order basis, giving name of part required, as well as the part number, model number and description of the complete circulation heater.
Parts Common To All Heaters
Temperature Control Thermostat . . . . . . . . . . . . . . . . . . . .300-057474-001
Automatic Reset Cutout . . . . . . . . . . . . . . . . . . . . . . . . . . .300-026629-005
O-Ring Gasket P/N . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132-057731-001
Heater Assembly
(Heating element
Model Volts kW and flange only)
CVCHS-151 120 1.5 155-058147-007
CVCHS-151 240 1.5 155-058147-008
CVCHS-201 120 2.0 155-058147-001
CVCHS-201 240 2.0 155-058147-002
CVCHS-251 120 2.5 155-058147-003
CVCHS-251 240 2.5 155-058147-004
CVCHS-301 120 3.0 155-058147-005
CVCHS-301 240 3.0 155-058147-006
Limited Warranty:
Please refer to the Chromalox limited warranty applicable to this product at
http://www.chromalox.com/customer-service/policies/termsofsale.aspx.
