Model 380, Co-planar beam load cell, Tedea-huntleigh

www.vpgtransducers.com
1
Model 380
Technical contact in Americas: [email protected];
Europe: [email protected]; Asia: [email protected]
Document No.: 12075
Revision: 26-Jul-2012
Co-Planar Beam Load Cell
FEATURES
• Capacity range: 7.5–250 kg
• Only 2.5–8 mm high
• Very low profile
• Aluminum construction
• IP65 protection
• 1000Ω input impedance
• Provides freedom in rectangular scale size design
• Matched output and current calibration circuitry
• Eliminates need for spyder in typical bench top scales
APPLICATIONS
• Personal scales
• Commonly used in low profile infant and adult medical
scales
• Large and medium low profile platform scales
• Airport baggage scales
• Postal scales
DESCRIPTION
Model 380 is a very low profile planar beam design,
allowing direct mounting in low profile platform scales.
The range of capacities and low profile make Model 380
most suitable for use in a wide range of applications.
OUTLINE DIMENSIONS in millimeters
L
A
B
C
W
D
ØQ1
ØQ2
1500.0
H
Type
L
A
B
C
D
W
H
Q1
Q2
PB-7.5kg
70
14
28
4.9 27.8 39
2.5
5.1
5.1
PB-37.5kg 76.2
15
29.3
6
30
44.5 4.8
6.2
6.6
PB-50kg
84.5
15
34
6.4
30
55
5.3
7.6
6.6
PB-75kg
84.5
15
34
6.4
30
55
6.4
7.6
6.6
PB-150kg 107.5 22.8 45.9 7.8 44.5 70
8
8.2 OR
5/16UNC 8.1
Type
L
A
B
C
D
W
H
Q1
Q2
PB-7.5 kg
70
14
28
4.9
27.8
39
2.5
5.1
5.1
PB-15 kg
70
14
28
4.9
27.8
39
4.1
6.2
5.1
PB-37.5 kg
76.2
15
29.3
6
30
44.5
4.8
6.2
6.6
PB-50 kg
84.5
15
34
6.4
30
55
5.3
7.6
6.6
PB-75 kg
84.5
15
34
6.4
30
55
6.4
7.6
6.6
PB-150 kg
107.5
22.8
45.9
7.8
44.5
70
8
5/16UNC
8.1
PB-250 kg
107.3
22.9
45.8
7.9
44.5
70
10.0
9.1
8.1
Co-Planar Beam Load Cell
Document No.: 12075
Revision: 26-Jul-2012
Model 380
