6
ADX5655z
4. NOMENCLATURE
Note:
• Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold).
itre.
1 RPT (repeat) indication
2 RDM (random) indication
3 Operation status indication
∗
The frequency, play time, clock, T-scan,
D-scan etc. are displayed.
4 Z-EHCR (z-enhancer) indication
5 MANU (manual) indication
6 ST (stereo) indication
7 Preset channel indication (1 to 6)
Disc number indication (1 to 12)
∗
The disc numbers corresponding to the discs
in the CD or MD changer light.
8 Function mode indication
∗
The names of modes being selected, etc. are
displayed.
9 B NR (Dolby NR) indication
0 BLS (blank skip) indication
! LOUD (loudness) indication
Names of Buttons
! BAND (band) button
TOP button
PROG (programe) button
@ ENT (enter) button
Play/pause button
# TITLE button
ADJ (adjust) button
$ TAPE EJECT button
% Left button
¥ Right button
& Up button
* Down button
( A-M (audio mode) button
LOUD (loudness) button
) CD EJECT button
¡ CD insertion slot
™ Cassette tape insertion slot
Display Items
In
1.
2.
No
Us
plo
• W
w
• D
ie
• D
• D
Re
1 Preset buttons (1 to 6)
Direct buttons (1 to 6) (7 to 12)
2 Z-EHCR (z-enhancer) button
3 DISP (display) button
4 SPE-ANA (spectrum analyzer) button
5 SCN (scan) button
PS/AS (preset scan/auto store) button
6 RPT (repeat) button
BLS (blank skip) button
7 POWER button
FUNC (function) button
8 RDM (random) button
B NR (Dolby NR) button
9 ISR (instant station recall) button
0 MUTE button
