17
1.4 Basic Specifications
Printing Method Direct line thermal printing
Printing Speed Max. 80mm/sec
Resolution 203 DPI x 203 DPI
Print width 48mm, 384dot
Character ALPHA NUMERIC Character, Extension Character
18 codepages, 14 international characters
Font Font A (12 x 24 dot), Font B (9 x 17 dot)
Number of columns 32 (Font A), 42 (Font B)
Barcode EAN-8, EAN-13, Code39, ITF, UPC-A,
Codabar, Code93, Code128, PDF417(2D)
Emulation ESC/POS
Driver Window CE 4.2&5.0, Window Mobile 5.0
Sensor Paper End Sensor, Gap Sensor, Cover Open Sensor
Paper Paper type Thermal Paper
Width 58mm
Thickness 65µm
External Diameter Max. Φ 48mm
Internal Diameter 12.5mm +/-0.5mm
Reliability Thermal Head 50km
Battery Continuous printing for 90min
Standby for 24hours
Communications Standard Serial(RS-232C), USB, Bluetooth Class2 (CMP-20BT),
Wireless Lan 802.11b/g (CMP-20WF)
MSR (Optional) Card Standard ISO7811/2
Track Track1, Track2, Track3
Magnet Head Life 300,000 Passes (minimum)
IC CARD (Optional) EMV level one certified smart card reader
Battery Charger Input AC100~240V, 50/60 Hz
Output 8.4V , 1200 mA
Battery Battery type Li-ion
Output 7.4V, 1800mAh
Charging time 2 hours
Size 96(W) x 136(D) x 58(H) mm
3.7(W) x 5.3(D) x 2.2(H) inch
Temperature Operation 5~40℃
Storage -10~50℃
Humidity Operation 35 ~ 95%
Storage 10 ~ 95%
