On back of grill, slide grease tray into opening in upper back panel.
CAUTION
Failure to install grease tray will
cause hot grease to drip from bottom
of grill with risk of fire or property
damage.
.
16
17
21
Assembled
warming rack
Place cooking grates onto the firebox as shown. Insert the two wire ends at rear of warming rack into holes in back of
firebox. Front wires of warming rack rest on sides of firebox.
Note: Some parts omitted for
clarity of illustration
Warming rack
Cooking grate
Grease tray
