2 Installing the Telephone
16 Install the Base Unit on a Standard Wall Plate
User’s Guide
Install the Base Unit on a Standard Wall Plate
This section provides procedures to mount the base unit on the wall if a standard
wall plate, with a telephone jack connected to the PARTNER ACS, is installed in
the wall.
If you want to mount the base unit on the wall and a standard wall plate is not
installed, go to
“Install the Base Unit Directly on a Wall” on page 19 .
!
CAUTION:
Do not mount the base unit on the ceiling.
1 To attach the wall mount stand to the base unit, slide the wall mount stand
into the notches at the top of the base unit. Then pull the wall mount stand
down and snap it into place.
Figure 4: Attach Wall Mount Stand to Base Unit
