Installing Options
3-2 Installation
3. Remove the tape seal on the non-conductive bag to remove the 2H253-25R.
4. Perform a visual inspection of the device for any signs of physical damage. Contact Cabletron
Systems if there are any signs of damage. Refer to
Section 1.2 for details.
3.2 INSTALLING OPTIONS
If the 2H253-25R is to be installed with an optional HSIM or VHSIM, refer to the user’s guide of
that device for the installation instructions.
3.3 INSTALLING THE DEVICE
The 2H253-25R may be installed on a tabletop, shelf, or in a 19-inch rack. Section 3.3.1 describes
a tabletop or shelf installation and Section 3.3.2 describes the rackmount installation.
Table 3-1 Contents of 2H253-25R Carton
Item Quantity
2H253-25R 1
Antistatic Wrist Strap 1
Console Cable Kit 1
Rackmount Kit 1
Strain-Relief Bracket 1
Manual Accessory Kit 1
Power Cord 2
NOTE
Install any optional equipment before proceeding to Section 3.3 .
To prevent possible personal injury and/or damage to the unit, do NOT connect power to
the 2H253-25R until instructed to do so.
