© 2009 Jaypro Sports Equipment JSL-Inst036 Rev C 06-05-2009 2 of 12
*** Bleacher To Be Assembled by Qualified Personnel Only ***
Note:
1) Unpack all parts and check against parts list to ensure that all parts have been included.
2) Inspect all parts for damage. Report any damages to the trucking company.
3) These instructions are for assembling both a 15 ft and 21 ft wide, 10-row bleacher. The part
quantities listed are for both bleachers.
Part List
Item # Quantity Part Number Part Description
SEATING COMPONENTS
1 6/8 BLCH-5L 5-ROW BLEACHER LEG
2 8/12 BLCHX-80 X-BRACE x 80” L, 5 TH ROW
3 12/18 BLCHX-77 X-BRACE x 77” L, 10 ROW BASE
4 8/12 BLCHX-76 X-BRACE x 76” L, 3 RD ROW
5 3/4 BLCH-10F 10 ROW BASE FRAME
6 3/4 BLCH101 FRAME CONNECTOR BRACKET
7 31 AR5043 / AR5052 STADIUM SEAT PLANK, 1 ½” x 9 ½” x 15 ft / 21 ft
SEATING HARDWARE
8 170/225 AR5044 5/16” BOLT CLIP
9 62 AR5045 SEAT PLANK END CAP
10 18/24 HB5030 5/16”-18 x 3” CARRIAGE BOLT, ZP
11 185/235 HB5054 5/16”-18 x 1-1/4” CARRIAGE BOLT, ZP
12 6/8 HB4078 5/16”-18 x 1-1/2” CARRIAGE BOLT, ZP
13 75/100 HN5042 3/8”-16 FLANGE HEX NUT, ZP
14 195/260 HN5046 5/16”-18 FLANGE HEX NUT, ZP
15 10/15 HS289 3/8”-16 x 2” HEX HD CAP SCREW, ZP
16 65/85 HS287 3/8”-16 x 1-1/4” HEX HD CAP SCREW, ZP
17 130 HS5035 #8 x 1/2” PHILLIPS PAN HD SCREW, SELF DRILL
GUARD RAIL HARDWARE
18 19/20 EP0018 2” x 2” BLACK SQUARE TUBE CAP
19 16 HS5157 3/8”-16 x 2-1/4” BUTTON HD CAP SCREW, SS
20 18/20 HS5163 3/8”-16 x 2-3/4” BUTTON HD CAP SCREW, SS
21 35/38 HW2151 3/8” SAE FLAT WASHER, SS
22 35/38 HN5040 3/8”-16 SLAB BASE TEE NUT, SS
GUARD RAIL COMPONENTS
23 3/4 GR-RP REAR SUPPORT POST
24 6 GR-SP SIDE SUPPORT POST
25 2 GR-CP CORNER POST
26 2/3 GR-B GUARDRAIL PANEL – BACK x 71-3/4” Wide
27 2 GR-F GUARDRAIL PANEL – BACK END x 17-3/8” Wide
28 2 GR-S GUARDRAIL PANEL – REAR SIDE x 29” Wide
29 2 GR-10S-1 GUARDRAIL PANEL – MID SIDE x 60” Wide
30 2 GR-10S-2 GUARDRAIL PANEL – FRONT SIDE x 71-3/4” Wide
