WARNING: The slider post is spring loaded and can extend rapidly. To
prevent serious or fatal injury, do not cut the strap holding the
post in place or loosen the quick-adjust knob[1] on the
height adjust handle until instructed to do so.
IMPORTANT: Unpacking and assembling the PBB-200 will require two or
three people in good physical condition each capable of
lifting 80 to 100 lbs (36 to 45 kg).
1. Using a forklift or pallet jack, place pallet on a level surface.
2. Carefully use a utility knife to remove wrapping.
3. Unpack all boxes and lay out contents.
4. Remove the three 3/8” bolts that secure the base to the pallet.
5. This step requires three adults: two to handle the PBB-200 and one to
remove the pallet. Slowly tilt the PBB-200 backwards until the rear
wheels touch the ground. Raise the front end of the unit off the
pallet. Remove the pallet and lower unit to the ground.
3.5 Base Set Up
1. Remove strap holding fixed post in place.
WARNING: DO NOT REMOVE STRAP FROM SLIDING POST.
2. Lift fixed post by handle until it the slots at the top of the fixed post
hook onto the top hinge of the mast.
WARNING: LIFT FIXED POST FROM HANDLE ONLY TO AVOID CRUSHING
FINGERS IN PINCH POINTS.
3. Secure assembly by tightening the knob on the hinge assembly.
4. Remove both base covers.
