4. Tighten quick-adjust cam lever to pin rim at desired height.
4.2 Folding to Transport Position
WARNING: NEVER MOVE UNLESS BACKBOARD IS LOWERED TO TRANSPORT
POSITION.
1. Lower rim to the minimum height.
2. Support the extension post/backboard/rim with one hand and
remove the quick-release pin. Pivot extension post downward until
backboard rests against mast padding.
3. Reinsert quick-release pin into extension post.
4. Loosen knob on hinge assembly between mast and fixed post.
5. Pull handle on back of fixed post to lower backstop into transport
position.
6. Raise feet and lower front wheels by raising lever on side of base.
4.3 Storage & Use
 The PBB-200 may be used indoors or outdoors, though it is not
designed to be stored outdoors.
 Exposure to precipitation will cause components to rust.
 Always store indoors.
4.4 Lubrication
 Lubricate all pivot points and other moving components at least
once a season or more, as necessary.
 Generously apply light oil to the exposed surfaces of the shaft
to which the feet are attached.
 Use heavy grease where possible and light oil in tight areas.
 Follow instructions included with rim for lubricating rim breakaway
mechanism.
4.5 Cleaning
 The exterior of the PBB-200 is powder-coated for a rugged, rust-
inhibiting finish.
