3.7 Leveling backboard and rim
1. Ensure that feet are lowered on base an set rim to 10’ playing
height.
2. Verify that backboard and rim are level and plumb using a
carpenter’s level.
3. If board is out of level, loosen bolts fastening rim and board to
extension post as well as screws fastening support arms to
backboard and adjust as necessary.
4. If board is not plumb, loosen bolt fastening extension post to support
arms and adjust as necessary.
5. Wrench-tighten all hardware.
3.8 Attaching Pads
1. Ensure that feet are lowered on base.
2. Rest bottom pad against the front of the base with the bottom of
the pad resting on top of the feet. Ensure that the pad is centered
with respect to the base.
3. Fasten pad to base using four #12 x ½” wood screws and #12
washers.
4. Place top pad against the mast with the bottom of the pad resting
on top of the bottom pad.
5. Fasten pad to base using four #12 x ½” wood screws and #12
washers.
4 Operation & Maintenance
4.1 Raising/Lowering Rim
WARNING: DO NOT ATTEMPT TO RAISE THE RIM UNLESS THE FEET ARE
LOWERED AND THE FRONT CASTERS ARE OFF THE GROUND.
1. When raising for the first time, loosen the hex head bolt on the
height adjust handle about ½ turn, until the washer can be rotated
freely.
2. Hold onto the height adjust handle and loosen quick-adjust knob.
3. Adjust the rim height by raising or lowering height adjust handle.
Numbers on side of slider post display rim height.
