ELITE Series Adjustable Portable Backstop Instructions
- 5 of 27-
JSL-Inst039
www.jayprosports.com
Figure 5-5: FP-90 Floor Anchor (1X)
Figure 5-6: ½"-13 Eyebolt w/ shoulder (1X)
Figure 5-7: Shackle (2X)
Figure 5-8: Twisted chain (8”)
5.4 Backboard
Figure 5-9: Backboard (72" board supplied w/ PBEL96
& PBEL 66, 54" with PBEL54)
Figure 5-10: Left (viewed from court) backboard
support arm (1X).
Figure 5-11: Right (viewed from court) backboard
support arm (1X).
5.5 Backboard hardware kit
Figure 5-12: 5/16”-18 Flanged Hex Nuts (2X)
Figure 5-13: 5/16”-18 x 1-1/8” Carriage Bolt (2X)
Figure 5-14: 5/16” Flat Washer (2X)
Figure 5-15: 5/16” Split Washer (2X)
Figure 5-16: 3/8”-16 x 1-1/2” Hex Bolt (2X)
Figure 5-17: 3/8” Flat Washer (2X)
