ELITE Series Adjustable Portable Backstop Instructions
- 2 of 27-
JSL-Inst039
www.jayprosports.com
1 Safety
 IMPORTANT: LIFT-ASSIST SPRINGS UNDER EXTREME TENSION. DO NOT ADJUST SPRINGS
WITHOUT CONSULTING MANUAL, SEE SECTION 12 (PAGE 25).
 IMPORTANT: DO NOT REMOVE SAFETY STRAP OR QUICK-RELEASE PIN UNTIL THE
BACKBOARD AND RIM HAVE BEEN INSTALLED. FAILURE TO COMPLY MAY RESULT IN
SEVERE OR FATAL INJURY AS WELL AS SIGNIFICANT DAMAGE TO SURROUNDING
STRUCTURES.
 Follow all warning labels on backstops.
 Do not stand directly behind uprights when raising or lowering the backstop.
 Be sure that area within 8 feet (2.5 meters) of backstop is clear of bystanders before
raising or lowering.
 Obtain assistance if lifting/lowering operation is too strenuous.
 Do not use backstop unless it is pinned at game-height using the supplied quick
release pin.
 Unit must be pinned in position using supplied quick-release pin at all times unless
raising or lowering.
 When raising or lowering, do not release handles unless backstop is pinned in position
with the supplied quick-release pin.
 Do not attempt to remove the backboard unless the unit is pinned in position with the
supplied quick-release pin.
 Do not hang on rim.
 Do not use power tools to raise or lower feet.
 Do not use backstop for gameplay unless feet have been lowered to game height.
 Inspect backstop for damage before and after each use.
2 Specifications
Extension Ballast
Standard
Backboard
Standard
Rim
Total
Weight
Jaypro Elite
9600 96” 1000 lbs
GBRUB-42
(42” x 72”) GBA-18042 2,600 lbs
Jaypro Elite
6600 66” 800 lbs
GBRUB-42
(42” x 72”) GBA-18042 2,400 lbs
Jaypro Elite
5400 54” 800 lbs 1
GBRUB-54 2
(42” x 54”) GBA-642 1,600 lbs
1 When PBEL54 shipped with 72” board (optional upgrade), 1000 lbs of ballast is included.
2 GBRUB-42 available as optional upgrade, must be specified at time of order
