Rev - B Page 2 of 13
JAYPRO SPORTS
BBC-SPDKT, INDOOR CABLE SUSPENDED BATTING TUNNEL KIT
IMPORTANT NOTICE:
1) DO NOT SET CAGE OR NET TOO CLOSE TO WALLS, COLUMNS, CEILINGS OR
ANY SOLID OBJECT WHERE BALLS CAN STRIKE AND BOUND BACK. CAGE OR
NET SHOULD BE AT LEAST 4 FEET FROM ALL BYSTANDERS, CEILINGS, WALLS
OR SOLID OBJECTS.
2) SPECTATORS MUST NOT STAND IN BACK OR NEAR SIDES OF CAGE OR NET
WHILE BEING USED FOR BATTING PRACTICE.
3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS
AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR
DEALER OR JAYPRO SPORTS.
4) CAUTION: DO NOT OVER TIGHT THE CABLES, AS EXTREME LOADING WILL BE
PLACED ON THE WALL OR END STRUCTURE.
PRODUCT DESCRIPTION:
The BBC-SPDKT, cable suspended batting tunnel kit is designed to attach to your existing building
structure, whether steel I-beam columns or reinforced (blocked) studded walls. 9/16” holes will
need to be drilled for the ½” eyebolts. If attaching to standard CMU block or concrete filled walls it
is recommended that a wood stringer wall mounting kit be used (model number BBC-WLKT), which
can be purchased separately. This kit includes six (6) attractive polyurethane finished 24” long, 2” x
8” stringers and mounting plates that are easy to install and help spread the load across multiple
CMU blocks or other wall types.
The height of the suspending cables should be cut to a length of about 12” below the height of the
netting itself. This will allow about 12” of netting the lay on the floor to capture the ball.
To maximize the overall width of your cage and overcome the nature sag due to the weight of the
net, a reinforcement spreader kit is available (model number BBC-SCKT) that will hold the top rigid
and maintain the nets width.
