Jas-Audio PLATO User Manual

Page 12

Drive Units per channel: Twin Aluminum ribbon tweeter with 5”face-plate (inch)

1” Top notch Ceramic Tweeter
5.5” ceramic-cone midrange unit

Two

9”

Ceramic-cone

woofers

Frequency Response:

20Hz - 25kHz ± 3dB, (20kHz–60 KHz ± 3dB with rear super tweeter on)

Sensitivity:

89 dB / 1W/ 1M

Nominal Impedance:

6 ohms

Min. Amplifier Power: 25 Watts per channel

Crossover Frequencies: 3000Hz and 300Hz , 10KHz and 14KHz (0db/+3db)

Speaker Dimensions:

W 13.7 x H 48.2 x D 26.4 (inch)

3 Packing Box Sizes:

Box A -> W 52 x H 43 x D 84 (inch)

Box B and C -> W 82 x H 63 x D 101 (inch)

Net Speaker Weight:

85kg per channel

Shipping Weight:

120kg x 2 + 60kg x 1 (Total Gross 300kg weight)

JAS AUDIO is constantly striving new design improvements, we reserve the right

to change or modify product specifications without prior notice or obligation.

Happy and Good Listening to all music lovers!

Best Regards,

Set your mind free!

Page 12 of 12

http://www.jas-audio.com
