errors.
4-3. ADVANCED CMOS SETUP
The
performance, or let you set up some system features according to your preference. Some entries here are
required by the CPU board’s design to remain in their default settings.
Advanced CMOS Setup
Quick Boot
This category speeds up the
Enabled, the BIOS will shorten or skip some check items during POST.
1st Boot Device
2nd Boot Device
3rd Boot Device
4th Boot Device
These options determine where the system looks first for an operating system.
Try Other Boot Devices
If you have other bootup device other than the above mentioned devices, such as IDE-0, IDE-1, IDE-3, IDE-4,
Floppy.
Floppy Access Control
This option determines the floppy access method, which can be either read only or normal (read/write). When
set to read only, the data in the floppy is allowed to be read instead of being written.” Normal” allows the
floppy to be read or written.
AMIBIOS SETUP - ADVANCED CMOS SETUP
(C) 1999 American Megatrends, Inc. All Rights Reserved
Quick Boot Enabled
1st Boot Device
Floppy
2nd Boot Device
IDE-0
3rd Boot Device
CDROM
4th Boot Device
Disabled
Try Other Boot Devices
Yes
Floppy Access Control Read-Write
Hard Disk Access Control Read-Write
S.M.A.R.T. for Hard Disks
Enabled
BootUp Num-Lock
On
Floppy Drive Swap
Disabled
Floppy Drive Seek
Disabled
PS/2 Mouse Support
Enabled
Typemaice Rate Fast
System Keyboard Absent
Primary Display VGA/EGA
Password Check
Setup
Boot to OS/2 > 64MB No
Wait For ‘F1’ If Error
Disabled
Hit ‘DEL’ Message Display
Enabled
Internal Cache
WriteBack
External Cache
WriteBack
Cache Bus Ecc Enabled
System BIOS Cacheable Enabled
C000, 16k Shadow
Enabled
C400, 16k Shadow
Enabled
C800, 16k Shadow
Enabled
CC00, 16k Shadow
Disabled
D000, 16k Shadow
Disabled
D400, 16k Shadow
Disabled
D800, 16k Shadow
Disabled
DC00, 16k Shadow
Disabled
Available Options :
Disabled
Enabled
ESC:Exit
:Sel
PgUp/PgDn:Modify
F2/F3:Color
