Connect Tech FreeForm/PCI-104 User Manual
Revision 0.00
24
Reference Design
The FreeForm/PCI-104 ships with a pre-installed reference design. This reference design demonstrates
how the FPGA interacts with the PLX 9056 PLX to local bus bridge.
Functionality
o
Local bus interface driven at 50MHz
o
Slave access to:
o
BAR2: 16x32 bit control registers , 16x32 bit user memory
o
BAR3: SPI flash programming interface
o
Master access to same 16x32 user memory as located in BAR2. Transfer controlled through
slave accessible registers.
o
Local bus master configuration of bridge (happens automatically with reset).
o
Single-ended GPIO control through registers.
o
LED control through registers.
Memory Map
Table 10: Bar Local Address Space 0 (Bar 2)
Local Address
(HEX)
Contents
Access
Description
00000000
INTERRUPT_MASK
R/W
Bit 0: Direct master state machine
Bit 1: SPI programmer
00000004
INTERRUPT_SOURCE
R
Bit 0: Direct master state machine
Bit 1: SPI programmer
00000008
REG2
R/W
UNUSED
0000000C
REG3
R/W
UNUSED
00000010
GPIO_P_OUT
W
Each bit corresponds to one GPIO pin output.
Direction must be set to output
Bit #: GPIO_P(#)
00000014
GPIO_P_TRI
W
Each bit corresponds to one GPIO pin direction
(1=Output)
00000018
GPIO_P_IN
R
Each bit corresponds to one GPIO pin input
Bit #: GPIO_P(#)
0000001C
GPIO_N_OUT
W
Same as GPIO_N_OUT
00000020
GPIO_N_TRI
W
Same as GPIO_N_TRI
00000024
GPIO_N_IN
R
Same as GPIO_N_IN
00000028
DM_STATE
R
Bits correspond to direct master states, refer to
plx32master.vhd for more details
0000002C
USER_LED
W
Bit 0: Led 1
Bit 1: Led 2
Bit 2: Led 3
Bit 3: Led 4
00000030
DM_CTRL
W
Bit 0: start operation, when complete must be
cleared before another operation can begin
Bit 1: Write = 1, Read = 0
00000034
DM_ADDR
W
Local bus destination address. Must match what
is programmed into PLX configuration register
DMLBAM.
00000038
DM_CNT
W
Number of DWORDs to transfer
0000003C
REVISION
R/W
Reference design revision
00000040 –
0000007C
R/W
User Memory
