20
SPECIFICATIONS (Continued)
Standard Settings
Microprocessor-based preset functions can store 32 sets of geometry settings
incluexcept the standard settings. The following industrial standard settings have
been pre-programmed by the factory.
Table 5. Standard Settings
No. Video Mode Name
(with Resolution and Vertical Frequency)
Horizontal
Frequency
p1500 p1600
1 VGA 640 480 - 60 Hz 31.47 kHz
2 VGA 720 400 - 70 Hz 31.47 kHz
3 VESA 800 600 - 85 Hz 53.67 kHz
4 VESA 1024 768 - 85 Hz 68.68 kHz
5 VESA 1280 1024 - 85 Hz 91.15 kHz
6 VESA 1600 1200 - 85 Hz 106.25 kHz
7 CPT 1600 1280 - 80 Hz 106.25 kHz
8 CPT 1600 1280 - 87 Hz 114.90 kHz
9 CPT 1600 1200 - 92 Hz 114.90 kHz
10 CPT 1856 1392 - 71 Hz 102.77 kHz
11 VESA 1920 1440 - 75 Hz 112.50 kHz
The following industrial standard settings have been pre-loaded by the factory.
Table 6. Standard Settings (Pre-loaded)
No. Video Mode Name
(with Resolution and Vertical Frequency)
Horizontal
Frequency
p1500 p1600
1 VESA 640 480 - 75 Hz 37.50 kHz
2 VESA 640 480 - 85 Hz 43.27 kHz
3 VESA 800 600 - 75 Hz 46.88 kHz
4 VESA 1024 768 - 75 Hz 60.02 kHz
5 VESA 1280
1024
- 75 Hz 79.98 kHz
6 VESA 1600
1200
- 75 Hz 93.75 kHz
