19
SPECIFICATIONS
CRT
21 inch type picture tube, 0.21 mm horizontal dot pitch, 0.20 mm horizontal mask pitch,
Invar shadow mask, Black matrix, Short persistence phosphors, Dark tint, Anti-Reflection
coat.
Input Signal
Video : 0.70 Vp-p, Analog
Sync. : Separate H/V, TTL level
Composite H/V, TTL level
Synchronisation
p1500 p1600
Horizontal : 31 - 107kHz 31 - 115 kHz
Vertical : 50 - 160 Hz 50 - 160 Hz
Resolution
Horizontal : up to 1856 dots up to 1920 dots
Vertical : up to 1392 lines up to 1440 lines
Viewable Image Size : 21 inches (508 mm), diagonal (typical)
Viewable Image Area
Horizontal : 406 mm (typical)
Vertical : 305 mm (typical)
Color Temperature
9300 : Standard color balance, 9300K
6500 : Standard color balance, 6500K
5000 : Standard color balance, 5000K
USER : User defined
DMS : Standard color balance, 9300K for the DMS mode
Power Supply
AC 100 - 120 / 200 - 240 V (auto select)
Power Consumption : 115 W (typical) (provided with power save circuit)
Warm-up Time : 30 minutes to reach optimum performance level.
Dimensions : 488 (W) x 482 (H) x 470 (D) mm ( including Tilt & Swivel Base)
Weight : 27.0 kg (approx.) (including Tilt & Swivel Base)
Heat Dissipation : 392BTU/Hr
Environmental Condition
Operating Temperature : 5 to 40 ºC
Operating Relative Humidity : 10 to 80 % without condensation
Storage Temperature
: -20 to 60 ºC
Storage Relative Humidity : 10 to 90 % without condensation
