EN 14 User Manual
TVM-2200 models
VESA modes
Resolution
(dots Xlines)
H freq. (KHz) V freq. (Hz) Remark
640 x 480 @ 60 Hz 31.5 60 Non-interlaced
640 x 480 @ 72 Hz 37.9 72 Non-interlaced
640 x 480 @ 75 Hz 37.5 75 Non-interlaced
800 x 600 @ 56 Hz 35.2 56 Non-interlaced
800 x 600 @ 60 Hz 37.9 60 Non-interlaced
800 x 600 @ 72 Hz 48.1 72 Non-interlaced
800 x 600 @ 75 Hz 46.9 75 Non-interlaced
1024 x 768 @ 60 Hz 48.4 60 Non-interlaced
1024 x 768 @ 70 Hz 56.5 70 Non-interlaced
1024 x 768 @ 75 Hz 60.0 75 Non-interlaced
1280 x 1028 @ 60 Hz 64.0 60 Non-interlaced
1280 x 1028 @ 75 Hz 804.0 75 Non-interlaced
1152 x 864 @ 75 Hz 67.5 75 Non-interlaced
1280 x 960 @ 60 Hz 60.0 60 Non-interlaced
1440 x 900 @ 60 Hz 55.935 60 Non-interlaced
1680 x 1050 @ 60 Hz 65.290 60 Non-interlaced
IBM modes
Resolution
(dots Xlines)
H freq. (KHz) V freq. (Hz) Remark
640 x 350 @ 70 Hz 31.5 70 Non-interlaced
720 x 400 @ 70 Hz 31.3 70 Non-interlaced
MAC modes
Resolution
(dots Xlines)
H freq. (KHz) V freq. (Hz) Remark
640 x 480 @ 67 Hz 35.0 67 Non-interlaced
832 x 624 @ 75 Hz 49.7 75 Non-interlaced
152 x 870 @ 75 Hz 68.7 75 Non-interlaced
MAC modes
Resolution
(dots Xlines)
H freq. (KHz) V freq. (Hz) Remark
1280 x 1024 @ 70 Hz 74.4 70 Non-interlaced
The LCD Monitor has only Non-interlaced modes without flicker
