EN 8 User Manual
2. MADi
Select advanced color engine for automatic
picture enhancement (2D/3D).
3. H-Size
Adjust the width (horizontal size) of the screen
image.
4. V-Size
Adjust the height (vertical size) of the screen
image.
5. H-position
Adjust the position of the display horizontally
(left or right).
6. V-position
Adjust the position of the display vertically (up
or down).
 System
1. Sleep Timer
Select time to turn off the monitor
(Off/15/30/45/60 minute).
2. Language
Select language for OSD (English/German).
3. OSD H-Position
Adjust the OSD position of the Display
horizontally (left or right).
4. OSD V-Position
Adjust the OSD position of the Display vertically
(up or down).
5. OSD Time out
Adjust the display OSD Menu (5 to60 seconds).
6. OSD Transparency
Adjust the OSD transparency.
7. Information
Shows the status of the current Display
settings.
8. Memory Recall
Reset the screen to the Factory Preset Display
settings.
Self-diagnosis
If there is no image, the Self-Diagnosis screen will
be displayed. The self-diagnosis function checks if
the status of the monitor screen is No Signal, Out
of Range or None Supported.
No Signal screen is displayed
when the D- Sub signal
connector is connected but
the status of the monitor is on
DPMS mode.
Out of Range screen is
displayed when the applied
frequency is under or over
normal range.
Normal range (Non-interlaced
mode only):
H: 30 to 80 kHz
V: 56 to 77 Hz
Check that the cable screen
is displayed when the analog
signal cable is disconnected.
Check that the cable screen
is displayed when the HDMI
signal cable is disconnected.
Removing the monitor stand
1. Turn off the monitor and unplug the power
cable.
2. Place a cushion or a soft cloth on the floor and
put the monitor on it with the front of the monitor
facing the floor.
3. Detach the rear cover of the monitor stand with
a screwdriver.
4. Remove the four screws connecting the stand
and monitor body. See pictures below.
