Interlogix TVM-2200 - Manual (Page 14)

EN 12 User Manual
TVM-2200 models
Items TVM-2200 model
Panel Screen size 22 in. (55.9 cm)
Pixel pitch 0.282 x 0.282 mm
View angle (H/V) 170°/160°
Contrast ratio 1000:1 (typ)
Response time 5 ms
Brightness 250 cd/m² (typ)
Recommended resolution 1680 x 1050 @ 60 Hz
Audio Speaker power 2 W x 2
Speakers Built-in
Sound features
Stereo R/L
Interface VGA in (15 Pin D-Sub) 1
HDMI in 1
Cam in/out 1/1
Audio in (RCA type) 1
PC stereo in Yes
Head phone out Yes
Power Consumption < 50 W
Source 12 VDC, 5 A
Special feature
Dimensions Filter type 3D comb filter,
deinterlacing
W x H x D (without stand) 523 x 367 x 66 mm
20.59 x 14.45 x 2.60 in.
W x H x D (with stand) 523 x 419 x 202 mm
20.59 x 16.50 x 7.95 in.
W x H x D (box) 464 x 186 x 550 mm
18.27 x 7.32 x 21.65 in.
Weight Net (without stand) 5.4 kg (11.9 lb.)
Net (with stand) 6.1 kg (13.4 lb.)
Gross (box) 7.7 kg (17.0 kg)
VESA mount
Specifications
Hole patterns
VESA standard 100 x 100 mm
(3.94 x 3.94 in.)
Spacing screw size M4 screw
Length 8.00 mm
Operating
temperature
0 to 40 °C (32 to 104 °F)
The specifications can change without notice.
The panel may have some defective pixels (ex. slightly light or dark) due to a characteristic of
the panel. But there is no defect in your panel product itself.
