4 Installation
Manual
Screws:
Hex wrench 95 x 50 mm
Drywall anchor
Φ7.5 x 24.5mm (3 pcs)
Screw M4
16 x 25mm (3 pcs)
Drill template (170 x 170 mm)
Installation manual
CD (Includes Configuration Manual,
Installation Manual, TruVision Device
Finder and Adobe Reader
Water joint (Provides water
resistance to network connection)
12 VDC Connector:
DC jack socket to terminal connectors
with positive and negative indicators
CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE
certified or LPS (limited power source) of the required output rating as listed on
the unit.
Cable requirements
For proper operation, adhere to the following cable and power requirements for
the cameras. Category 5 cabling or better is recommended. All network cabling
must be installed according to applicable codes and regulations.
