12 Installation Manual
Figure 3: Live view interface
Table 1: Overview of the Live View interface
Name Description
1. Live View Click to view live video.
2. Playback Click to playback video.
3. Log Click to search for event logs. There are three main
types: Alarm, Exception, and Operation.
4. Configuration Click to display the configuration window for setting
up the camera.
5. Current User Display current user logged on.
6. Logout Click to log out from the system. This can be done
at any time.
7. PTZ Controls Control pan, tilt, zoom actions, set up presets and
tour.
8. Aspect Ratio Choose the aspect ratio (4Ч3, 16Ч9 or auto).
9. Live View Mode Choose live view mode among 360 °, panorama,
and (or) PTZ mode.
