UltraView UVD-6120VE-2 Digital WDR Dome Camera User Manual
3
• Always use a 12 VDC or 24 VAC UL listed Class 2 power supply to power the
camera.
• Do not use the camera over the temperature range specifications: - 22 to
122°F (-30 to +50°C).
• If the light source where the camera is installed experiences rapid, wide-
variations in lighting, the camera may not operate as intended.
WARNING: To reduce the risk of fire or electronic shock, do not expose the
camera to rain or moisture and do not remove the cover or back.
Product description
Figure 1:: Camera description
Camera body
OSD control
pad
System heater
Power jack
Monitor output cable:
1. Monitor output BNC; 2.
Monitor output RCA
Video monitor output
Video output BNC
OSD control pad
The onscreen display (OSD) control pad (Figure 3) is a five-direction pad that
provides the ability to manually control the camera functions. Table 1 below lists
the OSD control pad functions and describes their use.
