8 UltraView UVD-6120VE-2 Digital WDR Dome Camera User Manual
Parameter Description
Default option is Off.
DNR Digital noise reduction (DNR) improves the image quality in low light
levels.
When enabled, select the Y and C filter strength: Press Return to return
to the previous menu or Exit & Save to save changes and return to live
mode. Default option is On.
Return Press Enter to return to the previous menu.
Exit & Save Exits the menu and returns to live mode. Saves changes made.
AE/WDR/BLC menu
Select the AE/WDR/BLC option from the Main menu to enter the AE menu.
Figure 7: The AE/WDR/BLC menu
Table 3: AE/WDR/BLC menu
Menu item Description
Lens type Defines the lens type used with the camera.
Select Fixed or DC . If DC is enabled, select the DC level and shutter speed
from the options shown.
WDR/BLC set Wide dynamic range (WDR) allows you to see details of objects in shadows or
details of objects in bright areas of frames that have high contrast between
light and dark areas such as the headlights of a passing car.
Backlight compensation (BLC) function improves image quality when the
background illumination is high. It prevents the object in the center from
appearing too dark.
Options are:
• Off
• WDR: Set the luminance level ( Low, Middle, High)
• BLC fix: set the BLC level (between 1 and 30) and the BLC window.
AGC max Defines the automatic gain control (AGM).
Select a value between 0 and 160.
Flicker This feature to prevent the strobing effect under certain lighting
conditions/shutter speeds.
Default option is Off.
Return Press Enter to return to the previous menu.
Exit & Save Exits the menu and returns to live mode. Saves changes made.
