UltraView UVC-6120-1 Digital WDR Camera User Manual

Figure 10: The Picture adjustment menu

Reset camera

Use this function to restore the camera parameters to the factory defaults values.
Select the

Reset

option from the Main menu to restore factory default values.

Specifications

Model

UVC-6120-1-P / UVC-6120-1-N

UVC-6120-1-P2

Lens type

C/CS-DC drive

Power supply

24 VAC / 12 VDC

96 to 240 VAC

Current

300 mA

50 mA

Power consumption

Max. 3.6 W

Max. 4.8 W

Operating temperature

-10 to +50 °C (14 to 122 °F)

Weight

390 g (0.85 lb.)

Dimensions

(Units = mm)

Side view :

Front view :
