8 UltraView UVC-6120-1 Digital WDR Camera User Manual
Programming
Once the camera hardware has been installed, the camera can then be
configured.
Access the Main menu
The Main menu provides access to the camera configuration options. The on-
screen display (OSD) is only available in English.
Program the camera by attaching a standard video monitor to the system.
Figure 4: The Main menu
Table 2: Main menu description
Menu item Description
General Defines the camera ID, mirror, and digital noise reduction (DNR) set up.
AE/WDR/BLC Defines the lens type as well as the WDR/BLC, AGC, and flicker set up.
WB mode Defines the white balance (WB) set up.
D/N mode Defines the day/night (D/N) set up.
Motion Defines the motion detection set up.
Privacy Defines privacy mask set up.
Pict adjust Defines the image quality functions.
Reset camera Resets the camera to factory default settings.
Exit & save Exits the menu and returns to live mode. Saves changes made.
To access the Main menu:
1. Press the OSD control pad ( Enter ) to access the Main menu and its
submenus.
2. Push the pad up, down, left and right to move between menu options.
3. Press the OSD control pad to select an option.
4. When in a sub menu, select Return to return to the previous menu.
5. To exit the Main menu, move the cursor to Exit at the bottom of the screen
and press Enter . All changes are saved.
