3BChapter 4: Basic setup
30 TruVision Mini PTZ 12X Camera User Manual
Preset tour settings
The function executes pre-positioning of the pan, tilt, zoom, and focus features in a
certain sequence for a dome camera. Before setting this function, you must have set
up at least two preset points.
This function is located on Main Page 2.
Preset Tours are saved as follows:
Preset Tour #1 = PTZ Tour 3
Preset Tour #2 = PTZ Tour 4
Preset Tour #3 = PTZ Tour 7
Preset Tour #4 = PTZ Tour 8
Preset Tour #5 = PTZ Tour 11
Preset Tour #6 = PTZ Tour 12
Preset Tour #7 = PTZ Tour 15
Preset Tour #8 = PTZ Tour 16
Figure 16: Preset Tour menu
Table 13: Preset Tour menu description
Function Description
Preset Tour Set up to eight preset tours.
Using the left/right direction keys, select a preset tour number and then
set its preset tour steps. This option is also called P Tour.
P Tour Step Set up to 64 points for each preset tour. The preset tour steps are order in
which the preset points are carried out by the camera. Preset position,
speed, and dwell time will also influence how the camera Show P Tours
through each preset tour step.
Preset Pos. Set a specific preset position to the selected preset tour step. You can
specify one of up to 255 preprogrammed positions. The unit will
automatically make the step after the last programmed step, which is an
End step. The Preset Tour will then loop and keep running.
Speed Set each preset tour step to a different speed, ranging from 01 to 15.
Within this range, pan, and tilt speed varies from 5 to 300 (degrees/sec.)
