TruVision TVD-2101/4101 Dome Camera User Manual 11
Menu Item Description
Gain Adjust gain value. The values range from 0 to 100.
Mode Only available when HSBLC is enabled. It can be set to NIGHT ONLY or
ALL DAY.
Mask level Define the mask level. The values range from 0 to 100.
Default Reset to default the backlight compensation setting and area.
Mask skip area Set the value to ON or OFF to enable or disable the mask skip area.
Return Exit the menu and return to live mode. Changes made are saved.
White balance
White balance (WB) tells the camera what the color white looks like. Based on
this information, the camera will then continue to display all colors correctly even
when the color temperature of the scene changes such as from daylight to
fluorescent lighting, for example.
In the Main menu, go to White Bal and select the options to be modified:
Menu Item Description
ATW ATW (automatic tracing white balance) will be used depends on the
lighting condition selected. It ensures reliable color reproduction when
lighting conditions change frequently.
AWB AWB (auto white balance). The camera automatically adjusts the white
balance.
AWC-SET WB is automatically adjusted to the current environment and locked at
this value.
Manual Manually adjust the white balance by blue gain only. The red gain is
automatically adjusted when the blue gain is changed. Only use this
function when there is steady light.
Return Exit the menu and return to live mode. Changes made are saved.
