NX-4 Control
Page 30
LOC PG DESCRIPTION DEFAULT DATA
AUXILIARY OUTPUT #1, EVENT & TIME
Segment #1: Program the event number for output #1.
0=Burglary alarm
47 19
Segment #2: Program the timing for output #1 here . 10 seconds
AUXILIARY OUTPUT #2, EVENT & TIME
Segment #1: Program the event number for output #2.
1=Fire alarm
48 19
Segment #2: Program the timing for output #2 here . 10 seconds
AUTOTEST CONTROL
Segment #1: Program a "1" if the interval is hours, a "0" if in
days. Add a
A2" to suppress the daily test or a A3" to suppress
the hourly test.
0
Segment #2: Program the autotest interval from 1-255 days
or hours.
24
Segment #3: Program the autotest report in 24 hour time
format. 2
51 20
Segment #4: Program the autotest report time, minutes
after the hour.
0
OPENING TIME
Segment #1: Program the hour of the opening time.
8
52 21
Segment #2: Program the minutes after the hour of the
opening time.
0
CLOSING TIME / AUTO ARMING TIME
Segment #1: Program the hour of the closing time/auto
arming time.
20
53 21
Segment #2: Program the minutes after hour of closing /
auto arming time. 0
DAYS OF THE WEEK SYSTEM IS OPEN 54 21
1
2
3
4 Sunday
Monday
Tuesday
Wednesday 5
6
7
8 Thursday
Friday
Saturday
Reserved
DAYS OF THE WEEK "AUTO ARMING" WILL OCCUR 55 21
1
2
3
4 Sunday
Monday
Tuesday
Wednesday 5
6
7
8 Thursday
Friday
Saturday
Reserved
LOC 56 - 83 COMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY
LOC PG DESCRIPTION DEFAULT DATA
56 22 RESTORE COMMUNICATOR CODE 14 _
57 22 BYPASS COMMUNICATOR CODE 0 _
58 22 TAMPER COMMUNICATOR CODE 0 _
59 22 TROUBLE COMMUNICATOR CODE 0 _
60 22 SENSOR LOW BATTERY COMMUNICATOR CODE 0 _
61 22 SENSOR MISSING COMMUNICATOR CODE 0 _
62 22 DURESS 0-0 _ _
63 22 AUXILIARY 1 0-0 _ _
