Port Connections

In Port

Connect the PoE IN port from following 802.3af PSE type
devices through a CAT-5e/6 UTP cable:

• PoE

injector

• PoE Injector Hub

• PoE Ethernet Switch

• Another

POE201-EX

Out Port

Connect the PoE OUT port to following 802.3af PD type
devices through a CAT-5e/6 UTP cable:

• PoE IP Camera

• PoE

VoIP

Phone

• PoE Wireless AP

• PoE

Splitter

• Another

POE201-EX

LED Indicators

POE201-EX LED indicators

LED

Color Function

PoE IN

Green Lights to indicate that the port is receiving

power.

LNK/ACT Green

Blink

Lights to indicate the port is link up.
Blink: Indicates the data activity through device.

PoE OUT Green Lights to indicate that the device is providing

power.
