10/100/1000Base-TX Port
LED
Color
Function
Lit: Indicates the link through that port is successfully
established.
TP
LNK/ACT
Green
Blinking: Indicate that the port is actively sending or
receiving data.
Lit: Indicates a 1000Mbps Full duplex connection.
TP 1000
Green
Off: Indicates a 10/100 Mbps Full duplex connection.
1000Base-SX/LX SFP Slot
LED
Color
Function
Lit: Indicates a successful link through the fiber port
.
Fiber
LNK/ACT
Green
Blinking: Indicates the data activity through the fiber port.
