IFS MC201-1P/1FS User Manual 9
Note:
The PoE feature requires the use of a recommended
power adapter.
LED Indicators
System
LED Color Function
PWR
Green Lit
Indicates the device is powered.
10/100Base-TX Port
LED Color Function
Blink
Indicates that the Media Converter is
actively sending or receiving data over that
port.
Lit
Indicates that the connection through the
port is successfully established. LNK/ACT
Green
Off
Indicates that the connection through the
port is not established.
Lit
Indicates that the port is providing PoE to
the connected device.
PoE in Use
Green
Off
Indicates that the port is not providing PoE
to the connected device.
100Base-FX SC Port
LED Color Function
Blink
Indicates that the Media Converter is actively
sending or receiving data over the port.
Lit
Indicates that the port link is up.
LNK/ACT Green
Off Indicates that the port link is down.
Note:
Fiber optic port should be set to the correct mode
according to this LNK/ACT indicator for optimal network
performance.
