LOCK-OUT DeViCe
P Series pistols are equipped with a patented HK Lock-Out ™ device. This component
replaces the lanyard loop insert in the frame and when engaged, locks the handgun’s
action by blocking any movement of the trigger, the hammer and the slide. The handgun
is locked and cannot fire until unlocked. The Lock-Out control plate is accessible through
the pistol’s magazine well (see Figure 30).
Figure 30
Turning the key clockwise 1/4 turn locks the action,
turning it counter-clockwise unlocks the action.
Clear the pistol and dry fire it prior to activating the Lock-Out device. Use the two pronged
key supplied with the pistol to lock or unlock the pistol as desired. When the holes on the
Lock-Out device are horizontally positioned, the pistol is locked and cannot be fired (see
Figure 31).
Figure 31 Figure 32
Locked position Unlocked/fire position
When the holes on the Lock-Out device are vertically positioned, the pistol is unlocked
and can be fired (see Figure 32).
WArNiNG: The HK Lock-Out device is not a substitute for safe gun handling
practices. Never point the muzzle of the pistol in an unsafe direction (at yourself or
others). When the Lock-Out device is placed in the locked position, the slide is locked
in the closed position and cannot be moved! Forcing the slide rearward while the
gun is in this locked position will damage the pistol.
For more information contact HK Customer Service.
P SerieS ACCeSSOrieS
The addition of industry standard mounting rails to P Series models (including a full Picat-
inny rail on the P30 and P30L), allows the widest variety of lights, laser aimers and acces-
sories to be added by simply sliding them onto the open rail system.
Figure 33 Figure 34
Light mounted on P2000 Detail of P2000 mounting rails
Follow the instructions of the manufacturer for installing, operating and removing
accessories from the mounting rails. Always ensure the P Series is “clear” and unloaded
before installing or removing accessories. Slide the accessory onto the rails until it locks
into the locking slot located on the bottom of frame.
Figure 35
Slide the accessory onto the rails
CAUTiON: improperly de signed or in stalled ac ces so ries may re sult in dam age to the
mounting grooves and/or the pistol. Such dam age is not cov ered under warranty. Be
certain to use only HK approved accessories and follow in stal la tion and pre cau tions
care ful ly.
For a complete list of accessories that fit the P30/ P30L/P30S and P2000/P2000SK Series,
contact HK Customer Service.
