E-8 E-9
UPRIGHT MoDE: TooL USAGE
TooL USAGE
1. Turn brush oFF.
2. remove hose from base hose connector on the lower portion of the cleaner. (Fig. 12)
3. remove handle from cleaner: push handle removal button and pull up on handle to
disconnect from body. (Fig. 13)
4. insert hose into handle hose connector and twist clockwise to lock in position. (Fig. 14)
5. push button on wand to extend telescoping wand. (Fig. 15)
6. Select the tool needed for above-floor cleaning and attach to end of wand.
CoNVERTING To CANISTER MoDE
CoNVERTING To CANISTER MoDE
1. remove hose from base hose connector. (Fig. 16)
2. Step on canister release pedal and pull body upward by canister handle. (Fig. 17)
3. Follow steps 3-5 in uprighT ModE: Tool uSagE section. (See above)
4. insert end of handle into hard floor nozzle.
5. canister mode.
Fig. 16
Hose
Base Hose
Connector
Fig. 17
Canister Release
Pedal
Base
Body
Canister
Handle
IMPoRTANT:
When returning to UPRIGHT mode hose MUST be removed
from handle and returned to inlet on body.
• after using the vacuum, store in upright mode.
• Store accessories on the storage clips located on the vacuum body.
• Wrap the cord around the cord storage hooks on the side of the body and hang the
plug at the cord clip on the wand. (Fig. 18)
SToRING IN UPRIGHT MoDE
Cord Clip
Plug
Cord
Fig. 18
Fig. 12
Hose
Base Hose
Connector
Handle
Removal
Button
Handle
Fig. 13 Fig. 14
Hose Handle Hose
Connector
Telescoping
Button
Handle
Fig. 15
Handle
Hard Floor
Nozzle
