VACUUM ASSEMBLy: UPRIGHT USE (CoNTD)
TooL ASSEMBLy
E-6 E-7
TooL ASSEMBLy
• attach crevice tool, dusting brush and upholstery brush into
storage area on the back of the vacuum. (Fig. 8)
Fig. 8
Upholstery
Brush
Dusting
Brush
Crevice
Tool
USING IN UPRIGHT MoDE
USING IN UPRIGHT MoDE
push the handle release pedal (Fig. 9)
• Turn main power switch on. Turn brush power switch on.
• CAUTIoN: The headlight and brush does not come on when in the upright
position even if the switch is on. you must release the handle for the brushroll
to begin spinning. (Fig. 10)
Fig. 9
Handle Release
Pedal
Fig. 10
Base Safety
Switch
Base
HEIGHT ADJUSTMENT KNoB
HEIGHT ADJUSTMENT KNoB
• rotate the height adjustment knob to the correct carpet height. (Fig. 11)
• To clean bare floor, set this knob to the bare floor position and turn off the brush power
switch. (located on the top of the cleaner - see page 2)
Fig. 11
HANDLE ASSEMBLy
HANDLE ASSEMBLy
• insert handle in the handle inlet on the top of the body. (Fig. 6)
HANDLE DISASSEMBLy
• push the handle removal button.
• pull handle upward to remove.
Fig. 6
Fig. 7
BASE ASSEMBLy
• Set the body on the top of the base. (Fig. 7)
• use both sides of the guide feature on the
base to align.
BASE DISASSEMBLy
• push the release canister pedal.
• lift up and remove the body.
BASE ASSEMBLy
Handle
Protrustion to Lock
Handle Inlet
Handle
Removal
Button
Guides Canister
Release Pedal
Base
