We have flown the RV-4 ARF extensively on a variety of
motors to find the best performance for this airplane. The
following items proved to power the plane very well, giving
similar performance to the .91 glow engine.
Motor
•
C50-65-450 RimFire ™ brushless out-runner
motor (GPMG4770)
• SS 80 Silver Series 80A ESC (GPMM1860)
• (4) 3 x 8mm Machine screws
• (4) 3mm Washers
Motor Mount
•
Brushless Motor Mount (large, GPMG1260)
Prop
•
APC 16x8E or 16x6 standard prop for a glow engine
Battery
We tested this plane with LiPo and NiMH batteries. The LiPo
batteries provided slightly longer flight times and weighed
less than the NiMH batteries.
• 6S1P 3200mAh LiPo battery (2) ElectriFly ™ 3200mAh
11.1V batteries, GPMP0623)
• One Series Adapter, (2) Deans males (GPMM3143)
or
•
12 volt (10-cell) 3600 NiMH battery with flat Deans
Connectors (GPMP0363)
We recommend the Great Planes ElectriFly PolyCharge 4 ™
LiPo charger (GPMM3015) for LiPo batteries and the Triton ™
Peak Charger (GPMM3150) for NiMH batteries.
❏
1/2 oz. [15g] Thin Pro ™ CA (GPMR6001)
❏
1 oz. [30g] Medium Pro CA+ (GPMR6008)
❏
Pro 6-minute epoxy (GPMR6045)
❏
Drill bits: 1/32" [.8mm], 1/16" [1.6mm], 5/64" [2mm],
3/32" [2.4mm], 9/64" [3.6mm], 3/16" [4.8mm].
❏
8-32 Tap and drill set (GPMR8103)
❏
R/C-56 canopy glue (JOZR5007)
❏
CA applicator tips (HCAR3780)
❏
Mixing sticks (50, GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Masking tape (TOPR8018)
❏
Threadlocker ™ thread-locking compound (GPMR6060)
❏
R/C foam rubber (1/4" [6mm] – HCAQ1000, or
1/2" [13mm] – HCAQ1050)
❏
3' [900mm] Standard silicone fuel tubing (GPMQ4131,
for glow engine installation only!)
❏
Fuel Filler Valve (for glow fuel GPMQ4160)
❏
Stick-on segmented lead weights (GPMQ4485)
❏
Silver Solder w/flux (GPMR8070)
❏
#1 Hobby knife (HCAR0105)
❏
#11 Blades (5-pack, HCAR0211)
❏
Small T-pins (100, HCAR5100)
❏
21st Century ® sealing iron (COVR2700)
❏
21st Century iron cover (COVR2702)
❏
21st Century trim seal iron (COVR2750)
❏
2 oz. [57g] Spray CA activator (GPMR6035)
❏
CA debonder (GPMR6039)
❏
Curved-tip canopy scissors (for trimming plastic
parts HCAR0667)
❏
Robart Super Stand II (ROBP1402)
❏
CG Machine ™ (GPMR2400)
❏
Rotary tool such as Dremel ®
❏
Rotary tool reinforced cut-off wheel (GPMR8020)
❏
Servo horn drill (HCAR0698)
❏
Hobby Heat ™ micro torch (HCAR0750)
❏
Dead Center ™ engine mount hole
locator (GPMR8130)
❏
AccuThrow ™ deflection gauge (GPMR2405)
❏
Denatured alcohol (for epoxy clean up)
• Sheet Metal Screws (SMS) are designated by a
number and a length. For example #6 x 3/4" [19mm].
This is a number six screw that is 3/4" [19mm] long.
• Machine Screws (MS) are designated by a number,
threads per inch, and a length. For example 4-40 x
3/4" [19mm].
This is a number four screw that is 3/4" [19mm] long
with forty threads per inch.
• Socket Head Cap Screws (SHCS) are designated by a
number, threads per inch, and a length. For example 4-40 x
1-1/2" [38mm].
IMPORTANT BUILDING NOTES
Optional Supplies & Tools
Adhesives & Building Supplies
ADDITIONAL ITEMS REQUIRED
Electric Motor & Motor
Mount Recommendations
