6

ADDITIONAL ITEMS REQUIRED

Adhesives and Building Supplies

1/4" [6mm] R/C foam rubber (HCAQ1000)

1/2 oz. [15g] Thin Pro

CA (GPMR6001)

1/2 oz. [15g] Medium Pro CA+ (GPMR6007)

Pro 30-minute epoxy (GPMR6047)

Threadlocker thread locking cement (GPMR6060)

Silver solder w/fl ux (STAR2000)

Great Planes .050" Ballwrench for screws in aileron servo

hatches (GPMR8000)

#1 Hobby knife (HCAR0105)

#11 blades (5-pack, HCAR0211)

Drill bits: 1/16" [1.6mm], 3/32" [2.4mm], 1/8" [3.2mm],

Small metal fi le

Optional Supplies and Tools

Great Planes 1/5-Scale Sport pilot:

GPMQ9015 Red, GPMQ9016 Blue,
GPMQ9017 Yellow, GPMQ9018 Unpainted

Robart Super Stand II (ROBP1402)

8mm prop reamer (for propellers and included spinner –

GPMQ5007)

Tap handle (GPMR8120)

Stick-on segmented lead weights (GPMQ4485)

2 oz. [57g] spray CA activator (GPMR6035)

R/C-56 canopy glue (JOZR5007)

CA applicator tips (HCAR3780)

CA debonder (GPMR6039)

Epoxy brushes (6, GPMR8060)

Mixing sticks (50, GPMR8055)

Mixing cups (GPMR8056)

Dead Center

Engine Mount Hole Locator (GPMR8130)

Denatured alcohol (for epoxy clean up)

Kevlar thread (for horizontal stabilizer alignment)

Panel Line Pen (TOPQ2510)

Rotary tool such as Dremel

Hobby Heat

micro torch (HCAR0755)

Covering Tools

The 21

st

Century covering iron and protective cover sock

are recommended for tightening the covering or removing
any wrinkles.

21

st

Century

®

sealing iron (COVR2700)

21

st

Century iron cover (COVR2702)

BUILDING NOTES

The Reactor .60 biplane ARF is factory-covered with

Top Flite

®

MonoKote

®

fi lm. Should repairs ever be required,

MonoKote can be patched with additional MonoKote
purchased separately. MonoKote is packaged in six-foot rolls,
but some hobby shops also sell it by the foot. If only a small
piece of MonoKote is needed for a minor patch, perhaps a
fellow modeler would give you some. MonoKote is applied
with a model airplane covering iron, but in an emergency a
regular iron could be used. A roll of MonoKote includes full
instructions for application. Following are the colors used on
this model and order numbers for six foot rolls.

White:

TOPQ0204

Orange:

TOPQ0202

Metallic

Blue:

TOPQ0402

Aluminum:

TOPQ0205

The stabilizer and wing incidences and engine thrust

angles have been factory-built into this model. However,
some technically-minded modelers may wish to check these
measurements anyway. To view this information visit the web
site at www.greatplanes.com and click on “Technical Data.”
Due to manufacturing tolerances which will have little or no
effect on the way your model will fl y, please expect slight
deviations between your model and the published values.

ORDERING REPLACEMENT PARTS

Replacement parts for the Great Planes Reactor .60
bipe ARF are available using the order numbers in the
Replacement Parts List that follows. The fastest, most
economical service can be provided by your hobby dealer
or mail-order company.

To locate a hobby dealer, visit the Great Planes web site at
www.greatplanes.com. Choose “Where to Buy” and follow
the instructions provided on the page to locate a U.S.,
Canadian or International dealer.

Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721,
but full retail prices and shipping and handling charges will
apply. Illinois and Nevada residents will also be charged
sales tax. If ordering via fax, include a Visa

®

or MasterCard

®

number and expiration date for payment.

Mail parts orders and payments by personal check to:

Hobby Services

3002 N Apollo Drive, Suite 1

Champaign IL 61822

Be certain to specify the order number exactly as listed in
the Replacement Parts List. Payment by credit card or
personal check only; no C.O.D.

If additional assistance is required for any reason contact
Product Support by e-mail at productsupport@greatplanes.
com, or by telephone at (217) 398-8970.
