If you have not flown this type of model before, we
recommend that you get the assistance of an experienced
pilot in your R/C club for your first flights. If you’re not a
member of a club, your local hobby shop has information
about clubs in your area whose membership includes
experienced pilots.
In addition to joining an R/C club, we strongly recommend you
join the AMA (Academy of Model Aeronautics). AMA
membership is required to fly at AMA sanctioned clubs. There
are over 2,500 AMA chartered clubs across the country.
Among other benefits, the AMA provides insurance to its
members who fly at sanctioned sites and events. Additionally,
training programs and instructors are available at AMA club
sites to help you get started the right way. Contact the AMA at
the address or toll-free phone number below:
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302-9252
Tele. (800) 435-9262
Fax (765) 741-0057
Or via the Internet at: http://www.modelaircraft.org
This is a partial list of items required to finish the Extra 300S
that may require planning or decision making before starting to
build. Order numbers are provided in parentheses.
Four channel radio and four channel receiver (a six channel
computer radio and six channel receiver may offer you
more setup options)
(4) servos with a minimum torque rating of 54 oz. in.
(1) servo with a minimum torque rating of 87 oz. in.
(1) servo with a minimum torque rating of 30 oz. in.
(3) 24" [610mm] servo extensions (HCAM2711 for Futaba)
(2) 12" [305mm] servo extensions (HCAM2721 for Futaba)
(2) Y-connectors (HCAM2751 for Futaba) (the Y-connectors
may be omitted if your radio system has the correct
mixing capabilities)
(1) Servo reverser (Because the elevator servos move in
opposition, either a transmitter capable of electronic
mixing must be used (so one of the servos can be
reversed) or a separate in-line mixing device such as the
Futaba SR-10 Synchronized Servo Reverser (FUTM4150)
must be used to reverse one of the servos.
(1) Radio switch harness
(1) 4.8v 1000 mAh battery (minimum)
Recommended engine size range for the Extra 300S 1.60 ARF:
1.20 to 1.60 two-stroke
or
1.20 to 1.80 four-stroke
In addition to the items listed in the “Decisions You Must
Make” section, following is the list of hardware and
accessories required to finish the Extra 300S. Order
numbers are provided in parentheses.
❏ R/C foam rubber (1/4" [6mm] (HCAQ1000) or 1/2"
[13mm] (HCAQ1050)
❏ Fuel filler valve for glow fuel (GPMQ4160)
❏ 1 oz. [30g] Thin Pro CA (GPMR6002)
❏ 1 oz. [30g] Medium Pro CA+ (GPMR6008)
❏ Pro 6-minute epoxy (GPMR6045)
❏ Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm],
7/64" [2.8mm], 1/8" [3.2mm],
❏ Silver solder w/flux (GPMR8070)
❏ #1 Hobby knife (HCAR0105)
❏ #11 blades (5-pack, HCAR0211)
❏ Sandpaper assortment
❏ Threadlocker thread locking cement (GPMR6060)
❏ 2 oz. [57g] spray CA activator (GPMR6035)
❏ CA applicator tips (HCAR3780)
❏ Mixing sticks (50, GPMR8055)
❏ Mixing cups (GPMR8056)
❏ Curved-tip canopy scissors for trimming plastic parts
(HCAR0667)
❏ Masking tape (TOPR8018)
❏ Denatured alcohol (for epoxy clean up)
❏ Rotary tool such as Dremel ®
❏ Servo horn drill (HCAR0698)
❏ AccuThrow ™ Deflection Gauge (GPMR2405)
❏ CG Machine ™ (GPMR2400)
❏ Precision Magnetic Prop Balancer ™ (TOPQ5700)
Optional Supplies and Tools
Hardware and Accessories
ADDITIONAL ITEMS REQUIRED
Engine Recommendations
Radio Equipment
DECISIONS YOU MUST MAKE
3
