Great Planes Extra 300S 1.60 ARF - GPMA1365 - Manual

WARRANTY
Great Planes ® Model Manufacturing Co. guarantees this kit to be free from defects in both material and workmanship
at the date of purchase. This warranty does not cover any component parts damaged by use or modification. In no case
shall Great Planes’ liability exceed the original cost of the purchased kit. Further, Great Planes reserves the right
to change or modify this warranty without notice.
In that Great Planes has no control over the final assembly or material used for final assembly, no liability shall be
assumed nor accepted for any damage resulting from the use by the user of the final user-assembled product. By the act
of using the user-assembled product, the user accepts all resulting liability.
If the buyers are not prepared to accept the liability associated with the use of this product, they are advised
to return this kit immediately in new and unused condition to the place of purchase.
READ THROUGH THIS INSTRUCTION MANUAL
FIRST. IT CONTAINS IMPORTANT INSTRUCTIONS
AND WARNINGS CONCERNING THE ASSEMBLY
AND USE OF THIS MODEL.
GPMZ0245 for GPMA1365 V1.0 Entire Contents © Copyright 2003
Champaign, Illinois
Telephone: (217) 398-8970 ext. 5
Fax: (217) 398-7721
INSTRUCTION MANUAL
Wingspan: 74 in [1880mm]
Length: 69 in [1755mm]
Wing Area: 1048 sq in [67.6 dm2]
Weight: 12-13.5 lb [5440–6120 g]
Wing Loading: 26-30 oz/sq ft [79-92 g/dm2]
Radio: 4 channel, 4 servos with a minimum torque rating of 54 oz. in.
1 servo with a minimum torque rating of 87 oz. in.
1 servo with a minimum torque rating of 30 oz. in.
Engine: 1.20 -1.60 cu in [19.5–26cc] two-stroke
1.20-1.80 cu in [19.5–29.5cc] four-stroke
