9
Flap Servo Installation (Optional)
Flaps are not necessary to land the 30cc Escapade. However,
if you have never fl own with fl aps, the 30cc Escapade is a
great plane to learn with.
❏
1. Install a servo lead extension (not included).
❏
2. Install grommets and eyelets in the fl ap servo .
❏
3. Remove the covering from fl ap servo opening.
❏
4. Separate the fl ap from the aileron.
❏
5. Install the fl ap servo following the same procedure used
to install the aileron servos.
❏
6. Install the fl ap servo in the right wing. The two fl ap
servos are connected with a Y-harness and plugged into the
fl ap channel on the receiver.
❏
7. Install the nylon wing dowels.
