7. Loosely install the fuel tank stopper screw.
❏
8. Slide the aluminum ring over the fuel tank neck.
❏
9. Secure the fuel tank stopper in the fuel tank. Mark the
top of the tank.
Install the Fuel Tank
❏
1. Install and mark the fuel lines: Vent, Carb and Fill.
❏
2. Secure the fuel tank in the fuselage.
❏
3. Route the fi ll line.
