Page 4

SERVICE PROCEDURES

ESCs that operate normally when received by Hobby Services will be
charged a minimum service fee and return shipping charges. Before
sending your ESC in for service, it is important that you review the
“Troubleshooting Guide” on this instruction sheet. The ESC may
appear to have failed when other problems exist in the system – such
as a defective transmitter, receiver or servo, or incorrect adjustments/
installation.

• Hobby dealers are not authorized to replace ESCs thought to

be defective.

• Do not cut the input wires of the ESC before sending it for service. A

fee will be charged for cut wires which must be replaced for testing.

180-DAY LIMITED WARRANTY (

USA

CANADA

ONLY

)

Great Planes

warrants this product to be free from defects in

materials and workmanship for a period of 180 days from the date of
purchase. During that period, we will repair or replace, at our option,
any product that does not meet these standards. You will be required
to provide proof of purchase date (receipt or invoice). If, during the
warranty period, your ESC shows defects caused by abuse, misuse or
accident, it will be repaired or replaced at our option, at a service
charge not greater than 50% of the current retail list price. Be sure to
include your daytime telephone number in case we need to contact
you about your repair. This warranty does not cover components worn
by use, application or reverse voltage, cross connections, poor
installation, subjection of components to foreign materials, any
alterations to wires or tampering. In no case shall our liability exceed
the original cost of the product.

Your warranty is voided if:

•

You apply reverse voltage to the ESC by connecting the motor
battery backwards.

• You allow any wires to become frayed which could cause a short.

• You use more than the rated number of cells in the motor battery.

• You tamper with any of the electronic components.

• You allow water, moisture or any other foreign material onto the PC

board.

Under no circumstances will the purchaser be entitled to consequential
or incidental damages. This warranty gives you specific legal rights,
and you may also have other rights which vary from state to state. If
you attempt to disassemble or repair this unit yourself it may void
the warranty.

For service to your ElectriFly ESC, either in or out of warranty, send it
post paid and insured to:

Hobby Services

3002 N. Apollo Dr. Suite 1

Champaign, IL 61822

(217) 398-0007

E-Mail: [email protected]
Internet Address: www.electrifly.com

SPECIFICATIONS

Input Volts:

6-12 NiCd/NiMH
2-4 LiPo (20V max w/o BEC)

7-14 NiCd/NiMH
4 LiPo (20V max w/o BEC)

35A cont. max (40A surge)

45A cont. max (50A surge)

Output Current:

Weight:

1.13oz. (32g)

1.76oz. (50g)

2.26oz. (64g)

Dimensions:

2.0 x 0.31 x 1.02" (52 x 8 x 26mm)

2.76 x 0.39 x 1.30" (70 x 10 x 33mm) 2.76 x 0.39 x 1.30" (70 x 10 x 33mm)

Thermal Cutoff:

230°F (110°C)

Low Volts Cutoff:

battery volts x 0.67

Brake:

on / off

On Resistance:

0.01 ohms

0.008 ohms

Operating Freq.:

8.5kHz

Max. Power:

350 watts

500 watts

BEC:

5V / 2.0A

SS-35

SS-45

SS-45D

Input Volts:

6-12 NiCd/NiMH
2-4 LiPo (20V max w/o BEC)

8A cont. max (10A surge)

12A cont. max (15A surge)

25A cont. max (28A surge)

6-12 NiCd/NiMH
2-4 LiPo (20V max w/o BEC)

Output Current:
BEC:
Max. Power:
Operating Freq.:
On Resistance:
Brake:
Low Volts Cutoff:
Thermal Cutoff:
Dimensions:
Weight:

0.39oz. (11g)

0.49oz. (14g)

0.92oz. (26g)

1.18 x 0.24 x 0.79" (30 x 6 x 20mm)

1.30 x 0.24 x 0.91" (33 x 6 x 23mm)

1.58 x 0.31 x 1.02" (40 x 8 x 26mm)

230°F (110°C)

battery volts x 0.67

on / off

0.05 ohms

0.03 ohms

0.015 ohms

8.5kHz

100 watts

150 watts

250 watts

5V / 1.5A

5V / 2.0A

SS-8

SS-12

SS-25

GPMZ0309

This manual is related to the following products:

Silver Series ESCs - GPMM1800-1841
